SOT Type Solid Hollow Shaft 20mm Ball Spline

Basic Info

Model No.: SOT020

Brand: HOJAMA

Place Of Origin: China

Status: New

Warranty: 1.5 years

Applicable Industry: CNC Machining Parts

Mechanical Test Report: Provided

Processing Technology: Grinding

Additional Info

Packaging: Wooden box

Productivity: 30000 sets/month

Transportation: Ocean,Land,Air,Express

Place of Origin: China

Supply Ability: 30000 sets/month

Certificate: ISO9001:2015

Port: Shanghai,Zhoushan,Dalian

Product Description

SOT020—20mm Diameter Ball Spline

The ball spline is a new type of linear motion system. The steel balls installed in the spline nut can perform smooth linear motion on the precise ground rolling surface of the spline shaft while transmitting torque.

The low-friction ball spline is mainly composed of a spline nut and a spline shaft：

1. Spline Nut:

The spline nut is a key part of the high-performance ball spline system. It has an internal raceway for steel balls, guiding their movement, transmitting load and torque, and ensuring system precision.

2. Spline Shaft

The high straightness spline shaft is machined with grooves of different numbers according to the number of rows of steel balls in the corresponding spline nut. The higher the straightness and roundness of the spline shafts are, the higher the precision of the ball spline will be.

Hojama offers a variety of products such as Ball Splines, ball screws, Lead Screws, Linear Guideways, and Linear Modules. Don't miss out, come and place your order now.
