SOF series ball spline features a square flanged spline nut.
1. Torque Transmission:
The steel balls moving within the angular contact groove enable relative motion between the nut and the screw shaft, facilitating torque transmission. This unique mechanism ensures efficient power transfer and smooth operation of the ball spline system.
2. Integral Structure:
The integral ball spline construction not only enhances the overall performance of the linear ball spline but also allows it to occupy less space, making it ideal for applications with limited space.
3. Easy Installation:
Thanks to the optimized retainer design, the ball nut can be effortlessly removed from the hollow or solid spline shaft, while the steel balls remain securely in place within the nut. This user-friendly installation feature simplifies the assembly process, saving time and effort during equipment setup.
4. Lubricant Path Optimization:
The lubricant path is optimized to directly lead grease to the ball track. This improvement in lubrication significantly enhances the lubrication effect, thereby increasing the service life of the ball splines. Adequate lubrication helps reduce friction and wear, ensuring long-term reliable operation of the system.
Apart from ball splines, Hojama can also supply ball screws, Lead Screws, linear guides, and Linear Modules. Come and make your purchase!
